Made from high quality aluminium alloy and case hardened piston rods this powerful and compact booster is suitable for vertical or horizontal mounting. Simplicity in design and high quality material selection makes this hydraulic booster suitable for many years of safe efficient and reliable operation. The micro series has five pressure outlet ports for connection to multiple devices. The pressure ports can be pressure feed to 65 Bar to allow cylinders to be brought into contact with the work piece prior to booster providing the final high pressure.
Metric Units
Switch to Imperial Units
Model No.
Intensification
100-20
25/1
100-18
30/1
Max. Air Pressure
Max. Oil Pressure
8.2-Bar
205-Bar
8.2-Bar
246-Bar
Max. Oil Output
Weight
31.5-CC
4.42-Kg
25.4-CC
4.42-Kg
Model No.
Intensification
100-20
25/1
100-18
30/1
Max. Air Pressure
Max. Oil Pressure
119-PSI
119-PSI
2975-PSI
3570-PSI
Max. Oil Output
Weight
1.92-CU IN
1.55-CU IN
9lb 12Oz
9lb 12Oz
